The ideal rig for sewer pipe drilling. Exactly round holes accurately positioned up to 350 mm diameter into sewer pipes is the specialty of this uniquely efficient machine.
The diamond core drilling system is designed for professional channel drilling up to 350 mm. This diamond channel core drilling system includes the CDM 23 WP core drilling machine with a 2.7 hp 2-stroke petrol engine, the CDR 350 channel core drill stand and a coordinated range of accessories. The 3-speed gearbox optimally exploits the engine torque and always drives the diamond core bit at the ideal speed when starting to suit the diameter of the cutting tool. Tool change is easy with the quick-release drill bit holder with integrated spindle protection.
This petrol driven sewer pipe drill rig makes a unique efficient core drilling system that optimally supports its user in every work situation. The drill stand is assembled using a tensioning ratchet when the sewer pipe is in an exposed position. If the sewer pipe is not completely accessible, the core drill rig is just as easily installed by anchoring it in the ground. The ergonomically placed hand crank wheel enables fatigue-free core drilling with both vertical and horizontal operation. The Teflon® coated support guide ensures lasting precision even under high loads with sliding sleeves and galvanized steel columns. The high stability of this innovative drill stand enables the precise angled drilling from 90 ° to 45 °. A useful detail is that crane eyelet, thanks to which the entire canal core drilling system can be lifted effortlessly and quickly into or out of the construction pit. The sewer pipe drill stand can, due to its universal mounting plate, be easily equipped with any electric drill motor. As tried-and-tested accessories a footboard unit, an excavator bucket frame and a water pressure tank are also available.
Drilling perfectly round holes for sewer pipes is the core competence of this extremely efficient and special machine. Explore all the features of the channel core drilling rig:
Key Features
User friendly – 3 speed gear box allows optimal rotational speed depending on the core drilling diameter
Maximum safety due to integrated centrifugal clutch (2-stroke gasoline motor) and mechanical overload clutch (3 speed gear box)
Knowledge Base
Why does choosing the right Drill-jet Channel core drilling system matter on a UAE project? An under-specified or poorly maintained drill-jet channel core drilling system slows a schedule down and is a common cause of on-site incidents, while a correctly specified, well-maintained unit keeps output consistent and meets the safety and quality standards expected on Abu Dhabi and Dubai construction and industrial sites.
How do I get pricing for the Drill-jet Channel core drilling system? Pricing for the Drill-jet Channel core drilling system depends on the exact specification and quantity required — submit a quote request through the enquiry form on this page or contact Sparkline Group directly, and our sales team will respond with a formal quotation.
Is the Drill-jet Channel core drilling system available for delivery across the UAE and GCC? Yes — Sparkline Group supplies and delivers the Drill-jet Channel core drilling system to project sites across Abu Dhabi, Dubai, Sharjah and the wider UAE, with support for GCC-wide delivery on request.
Does the Drill-jet Channel core drilling system meet UAE compliance and safety standards? Yes — the Drill-jet Channel core drilling system is supplied to meet the safety and quality standards expected on UAE construction and industrial sites, and Sparkline Group's technical team can advise on the certification or documentation your project requires.
What is Core Drilling Machine & Core Bits used for on UAE construction sites? Core Drilling Machine & Core Bits is a core equipment category for contractors, precast producers and industrial maintenance teams working across the UAE. Whether specified for a single project or kept as part of a standing fleet, the choice of machine in this category has a direct, measurable effect on output, finish quality, and site safety.
Why does choosing the right Core Drilling Machine & Core Bits matter? Getting Core Drilling Machine & Core Bits right matters for three practical reasons: output (the wrong capacity or spec slows a schedule down immediately), consistency (a well-maintained, correctly specified machine produces a more uniform result across a long pour or run), and safety (poorly matched or worn equipment is a leading cause of on-site incidents). On UAE projects — often running multiple shifts under summer heat conditions — reliability isn't a nice-to-have, it's what keeps a schedule intact.
What innovation trend is shaping Core Drilling Machine & Core Bits — Telematics and remote monitoring? Increasingly, UAE contractors are specifying models with built-in telematics — GPS location, engine-hour tracking, fuel usage, and fault alerts sent straight to a site manager's phone. On large Abu Dhabi and Dubai projects this cuts unplanned downtime significantly, since a developing fault is flagged before it causes a breakdown mid-pour or mid-shift.
Does Sparkline Group supply Core Drilling Machine & Core Bits in the UAE? Sparkline Group supplies and supports Core Drilling Machine & Core Bits across Abu Dhabi, Dubai and the wider UAE — sales, rentals, and genuine spare parts, backed by technical guidance on choosing the right specification for your project.
What should I look for when buying Core Drilling Machine & Core Bits in the UAE? Match the Core Drilling Machine & Core Bits to your project's duty cycle, site power supply, and required output capacity first — an undersized machine slows work down, while an oversized one adds unnecessary cost. Sparkline Group's sales team can confirm the right specification for your site before you order.
Which brands of Core Drilling Machine & Core Bits does Sparkline Group supply? We supply Core Drilling Machine & Core Bits from established manufacturers we hold direct distribution relationships with, backed by genuine parts and manufacturer-standard warranty support. Contact our sales team for the specific brands and models currently in stock.
Does Sparkline Group provide installation and after-sales support? Yes. Our engineers handle delivery, installation, and commissioning, and we stock genuine spare parts and offer ongoing maintenance support for every category we supply, including this one.
